| Element | Content(%) |
|---|---|
| Ti | Remaining |
| Al | 5.5-6.75 |
| V | 3.5-4.5 |
| Fe | ≤0.3 |
| O | ≤0.2 |
| C | ≤0.1 |
| N | ≤0.05 |
| H | ≤0.015 |
| Left each | ≤0.1 |
| Left total | ≤0.4 |
Titanium Grade 5 alloy is Ti-6Al-4V (titanium-6 aluminum-4 vanadium) alloy, is one of the most widely used grades in titanium alloys.
It is an α+β titanium alloy with enhanced overall performance achieved through the addition of aluminum (Al) and vanadium (V). Capable of long-term operation at temperatures between 300°C and 400°C while retaining high strength at elevated temperatures, Ti Gr.5 is frequently used in high-temperature applications; it is suitable for manufacturing aero-engine components—such as fan and compressor disks and blades—as well as aircraft airframe components like frames and fittings.
The mechanical properties of titanium Grade 5 alloy make it an irreplaceable material in the demands of "high strength, lightweight and corrosion resistance", especially as a core role in aerospace and medical care fields.
| Element | Content(%) |
|---|---|
| Ti | Remaining |
| Al | 5.5-6.75 |
| V | 3.5-4.5 |
| Fe | ≤0.3 |
| O | ≤0.2 |
| C | ≤0.1 |
| N | ≤0.05 |
| H | ≤0.015 |
| Left each | ≤0.1 |
| Left total | ≤0.4 |
| Processing status | Annealed | Solution aged | Hot Isostatic Pressing (HIP) |
|---|---|---|---|
| Tensile strength (MPa) | 895-930 | 1000-1100 | 950-980 |
| Yield strength (MPa) | 825-870 | 950-1050 | 880-920 |
| Fracture toughness (MPa√m) | 55-70 | 45-60 | 60-75 |
| Rotating-beam fatigue strength (MPa) | 500-550 | 550-600 | 520-570 |
