| Thickness (mm) | Width (mm) | Length (customizable) |
|---|---|---|
| 0.1 | Custom-made | Custom-made |
| 0.15 | Custom-made | Custom-made |
| 0.2 | Custom-made | Custom-made |
| 0.25 | Custom-made | Custom-made |
| 0.3 | Custom-made | Custom-made |
| 0.4 | Custom-made | Custom-made |
Ti-45Nb has a nominal composition of approximately 55% Ti and 45% Nb, corresponding to ASTM Grade 36 (UNS R58450).
This material belongs to the beta-type titanium alloy family; it features a low elastic modulus, good ductility and formability, and excellent corrosion resistance. Unlike structural titanium alloys such as Ti-6Al-4V, the primary value of Ti-45Nb lies in the unique physical and mechanical properties inherent to titanium-niobium alloys.
Ti-45Nb foil is produced through processes including vacuum melting, hot rolling, cold rolling, annealing, and precision slitting, and can be supplied in various thicknesses, widths, and lengths to meet customer specifications.
Classified as a beta-type titanium alloy, Grade 36 (Ti-45Nb) has a typical elastic modulus of approximately 45–60 GPa—significantly lower than that of conventional Ti-6Al-4V—making it suitable for applications requiring a low elastic modulus and high flexibility.
Can be used for: medical implants, orthopedic implants, dental applications, biomedical components, and medical equipment components.
Aerospace applications: lightweight structural components, flexible components, aerospace research, components made of special alloys.
Scientific Research: materials research, titanium alloy research, biomedical materials research, low-modulus alloy research.
Ti-45Nb foil can be used for certain applications: its thin gauge, high corrosion resistance, low modulus of elasticity, and the unique properties of the titanium-niobium alloy.
| Thickness (mm) | Width (mm) | Length (customizable) |
|---|---|---|
| 0.1 | Custom-made | Custom-made |
| 0.15 | Custom-made | Custom-made |
| 0.2 | Custom-made | Custom-made |
| 0.25 | Custom-made | Custom-made |
| 0.3 | Custom-made | Custom-made |
| 0.4 | Custom-made | Custom-made |
