| Thickness (mm) | Width | Length |
|---|---|---|
| 0.02–0.3 mm (customizable upon request) | In accordance with customer requirements | In accordance with customer requirements |
Nb-1Zr alloy foil has excellent high-temperature properties, creep resistance, and corrosion resistance, making it suitable for high-temperature thermal protection, vacuum equipment, nuclear power, the aerospace industry, power systems, and specialized engineering applications.
Nb-1Zr alloy foil of various thicknesses, widths, and lengths is available upon request and can also be custom-manufactured according to drawings, technical specifications, and application requirements.
Nb-1Zr foil can be used to manufacture heat shields, insulating layers, and thermal management components for high-temperature environments.
Nb-1Zr has excellent high-temperature properties and can be used in certain high-temperature components and thermal management systems in the aerospace industry.
Nb-1Zr foil can be used for: thermal protection of vacuum furnaces, internal protection of high-temperature furnaces, vacuum heat treatment equipment, high-temperature insulation components, and internal structures of vacuum equipment.
Niobium and niobium alloys have good corrosion resistance, so Nb-1Zr foil can be used in certain specialized corrosive environments.
Nb-1Zr foil can also be used for: high-temperature experimental equipment, vacuum experimental devices, research and development equipment, thermal control experiments, specialized mechanical engineering components, and custom-made products manufactured to specifications.
| Thickness (mm) | Width | Length |
|---|---|---|
| 0.02–0.3 mm (customizable upon request) | In accordance with customer requirements | In accordance with customer requirements |
| Mechanical Properties | Nb-1Zr |
|---|---|
| Tensile Strength, min. | 195 MPa |
| Yield Strength, 0.2% offset, min. | 125 MPa |
| Elongation, ≥0.254 mm thickness | 20% min. |
| Elongation, <0.254 mm thickness | 15% min. |
| Condition | Annealed, ≥90% recrystallized |
| Standard | ASTM B393 |
| UNS | R04251 / R04261 |
